Material :
Chrome brass (CB)Flow :
1/4 '' SizeSealing Ring :
Buna-N (Nitrile rubber)Color :
metallochromeValve Option :
ValveValve Spring :
316 Stainless SteelInternal Valve Material :
Acetal (POM)Classification:
Color and Material | Product Name | Operation temperature | O-ring |
(Metallochrome) Chrome brass / Stainless steel | SCBV4013B04 / SSSV4013B04 | - 40 ° F to 180° F | Buna-N (Nitrile rubber) |
Panel Mount Dimensions:
Panel Opening | Max Panel Thickness | Min Panel Thickness | |
Sockets | 0.688" | 0.5" | 0.05" |
Plugs | 0.688" | 0.3" | 0.05" |
Product Number Guide Example:
S | CB | V | 40 | 13 | B | 04 |
Socket / Plug |
Material |
Valve |
Flow size |
Body shape |
O-ring |
Connection size |
